Hot Racing TRA Steel Spur Gear, 50T 0.8 Mod, Green

About this part

Hot Racing 50 tooth, 32 pitch (0.8 mod) steel spur gear in green. It is made for the 1/10 TRA E-Revo, Rally VXL, Slash 4X4, and Stampede 4X4, and it works with the Hot Racing ATF25R02 gear adaptor for Arrma 4WD 3S and 4S vehicles. This is a speed run gear. It needs an oversize pinion, and it will run the motor hotter.

Features

• CNC machined and lightened hardened steel
• Black oxide coating for durability and corrosion resistance
• Green anodized countersunk washers

Includes

• One 50 tooth 32 pitch (0.8 mod) spur gear
• Three mounting screws
• Three green anodized countersunk washers
• Three washers, to place under the countersunk washers if the screw ends stick through the spur mounting plate

Specifications

• Teeth: 50
• Pitch: 32 (0.8 module)
• Mounting holes: 3
• Tooth face width: 6mm (0.24 inch)
• Inside diameter: about 11mm (about 0.43 inch)
• REQUIRES:
• A larger pinion gear
• A slipper transmission. This gear will NOT work with a center gear differential. Use Hot Racing SSLF2 series gears for vehicles with a center gear differential.
• FITS:
• Arrma 1:8 Vendetta 3S

Fits
