Castle Creations Mamba Micro X2 Waterproof Sensored ESC, 16.8V, 4.0mm

About this part

The Mamba Micro X2 refreshes the Mamba Micro X and raises the maximum input to 4S. It adds data logging and CRYO-DRIVE technology, which lets the ESC run cooler and more efficiently at partial throttle. Listed size: 4.0mm. This ESC suits weight-conscious or space-limited builds. It works for low speed crawling or trail running in vehicles up to 8 lbs on 2S or 3S, and for more aggressive setups such as rock racing and extended hill climbing in vehicles up to 4 lbs. Recommended motors are Castle's Slate crawler motors (combos available) and the Holmes Hobbies Puller Pro 540 Stubby (2700kv). For heavier, more aggressive rigs, the Mamba X ESC is the better choice. Rock crawling features include active drag brake and drag brake ramp.

Note

• An external BEC is required when running a high power or digital servo.

Features

• Input voltage 2S-4S
• Adjustable 5.5V or 7.5V (2A peak), default 5.5V
• Waterproof design
• Sensored motor capable
• Six common settings adjustable from the transmitter
