Hot Racing SCX24 Telescopic Shock, 3 Sections

About this part

Hot Racing aluminum three-section telescopic shocks for the Axial SCX24 and other mini or micro crawlers. These shocks are friction damped and need only a coating of tacky grease. The machined reservoir caps give them a scale look.

Features

• Machined aluminum and brass construction
• Telescopic design for maximum travel
• Threaded shock bodies for quick preload adjustment
• Scale-look reservoir, non-functional and for appearance only
• Three spring rates included

You will receive

• Four (4) three-section telescopic shocks
• Four (4) soft springs (black)
• Four (4) medium springs (gold)
• Four (4) firm springs (silver)
• Eight (8) M1.4x8 cap head screws

Requirements

• A 0.05in, 1.3mm, or 1.4mm hex wrench for the screws
• Tacky grease or silicone diff lube, applied for a heavy coating

Specifications

• Extended length, eye to eye: about 48.5mm
• Compressed length, eye to eye: about 28.5mm
• Stroke: 20mm
• Spring length: 32mm, 14 turn (0.3, 0.35, 0.4)

Notes

• Replaces the Axial AXI31612 SCX24 shock set. The reservoir is non-functional. Mount with the wide flange facing outward to retain the O-rings.

Fits

Replaces stock part
