Reefs RC Servo Gear Set for 422hdv2

About this part

A replacement gear set for the 422HDv2 servo, meant for use when installed in a working servo.

Specifications

• High torque digital coreless servo
• Submarine waterproof with seven-point seals
• Magnetic angle sensor, pulse width modulation control
• Fully programmable with REEFS software (REEFS Link required for programming)
• Voltage: 4.8V to 8.4V
• Internal: steel gears, all CNC aluminum casing
• Bearing type: three ball bearings
• Weight: 2.85 oz
• Dimensions (LWH): 1.57 x 0.78 x 1.5
• Torque: 360 oz at 6V / 400 oz at 7.4V / 434 oz at 8.4V
• Speed: 0.13 sec at 6V / 0.11 sec at 7.4V / 0.10 sec at 8.4V
• Spline: 25T
• Dead band width: 2s
• BEC not required, recommended for maximum performance
• FITS:
• HPI Nitro RS4 (belt, really old), HPI Nitro RS4 Nitro MT, Losi 1:10 NXT, Associated RC-8T3e, Losi 1:10 TEN-MT 4WD, Losi 1:8 8IGHT 4.0 Buggy

Fits
