Hot Racing Brass Heavy Metal HD Bearing Front Knuckle for SCX II

About this part

Hot Racing heavy duty brass AR44 steering knuckles (steering blocks) for the Axial SCX10 II and/or AR44 axles. Add weight to your crawler where it needs it - down low. Adds about 46g (1.6oz) to each steering knuckle.

Features

• CNC machined solid brass
• Heavy duty 5x13x4mm double-sealed outer bearing
• Heavy to add weight to vehicle for greater stability and lower CG
• Stainless steel kingpin bushings
• Cutouts on knuckle for access to outer bearing race for easy bearing removal
• With stainless kingpin bushings
• High strength steel hardware
• Direct replacement for factory plastic steering knuckles

You will receive

• Two (2) brass steering knuckles
• Four (4) stainless steel bushings M3(ID)x5(length)x4(OD) 6mmx.5mm flange.
• Four (4) kingpin screws

Specifications

• Height: 33.1 mm - weight 46g (1.6oz) each

Requirements

• Recommended to use a removable-type locking adhesive on screws threading into metal

Comments

• Replaces factory plastic Axial AX31381 steering knuckles
• Bearing installation tips: 1) Install 5x13x4mm outer bearing - 2) Use axle as a guide to Install 10x15x4mm inner bearing

Fits

Replaces stock part
