Hobbywing Ezrun 5690 Sd G2 Motor, 1250 Kv, Black

About this part

Ezrun 5690 SD G2 black brushless motor, 1250KV, rated for 3-8S LiPo. Waterproof sensored design: compared with the previous generation, this motor adds a waterproof sensor cable and a sensored system. The result is better acceleration linearity and stronger output. Matched with the Hobbywing EZRUN MAX5 G2 ESC, the motor is recognized automatically and runs in full sensor mode, for finer control and motor overheat protection. A separate high-precision encoder always sends a pure rotor position signal, which keeps sensor interference out of the system. Build: CNC-machined aluminum housing, high-purity copper windings, a high-strength explosion-proof rotor, ultrathin silicon steel laminations, a stainless steel output shaft, and high-precision bearings. The sensor interface and rubber cover bearings resist water and dust better than traditional sensored motors. Intended for maximum power in uber-sized vehicles (1/6, 1/5).

Specifications

• KV: 1250
• LiPo: 3-8S
• No-load Current: 6.6A
