Hobbywing Xerun 4268sd Black Motor, 2600kv, for Onroad & GT

About this part

The Xerun 4268sd Black is a 2600kv, 4-pole brushless motor for 1/8 on-road and GT vehicles.

Specifications

• KV: 2600
• Poles: 4
• Resistance: 0.0035
• No-load current: 6A
• Diameter / length: 42mm / 68mm
• Weight: 316g
• Vehicles: 1/8 on-road and GT
• Recommended weight: 3kg
• LiPo cells: 2S-6S

Features

• Suited to 1/8 short course trucks, buggies and touring cars.
• Turbo timing technology.
• Full sensored mode when paired with the XR8 SCT ESC or XR8 Plus ESC.
• Bi-directional adjustable timing from 20 to 40 degrees.
• Advanced Hall sensor system.
• Low cogging.
• 4-pole, 8-magnet staggered pole rotor, under Hobbywing's patent.
• Heat dissipation and dust prevention built in.
• Double-insulated windings rated 240°C, Japanese NMB bearings and high-strength adhesive rated 340°C for durability.
