Hitec/RCD RDX2 Mini AC Balance Charger

About this part

The RDX2 Mini is an AC balance charger with two built-in XT60 connectors, so it can run two packs at once. It supports AGM and cold-charge modes and a wide range of lithium, nickel and lead chemistries. Each channel delivers 50 watts, for 100 watts total.

Features

• LCD interface with 10 battery memory charge and discharge profiles
• AGM and cold charge modes
• Terminal voltage control
• Built-in balance connector
• Balance, standard, fast and storage modes for all lithium chemistries
• Re-peak charge mode and delta-peak sensitivity for NiMH and NiCd
• Optional temperature sensor for NiCd and NiMH charging
• Two built-in XT60 connectors
• Smart ventilation fan

Specifications

• AC input: 100 to 240V AC
• Charge power: 100 W (2 x 50 W)
• Charge current range: 0.1 to 5.0 A
• Current drain for LiPo balancing: 300 mA per cell
• NiCd/NiMH cell count: 6 to 8
• LiPo/LiHV/LiFe/LiIon cell count: 2 to 4
• Pb battery voltage: 6 to 12V
• Dimensions: 3.5 x 3.9 x 5.0 in (90 x 100 x 127mm)
• Weight: 1.1 lbs. (50kg)
• SET CONTAINS:
• RDX2 Mini charger
• AC cord
• Two T-type connectors
• FITS:
• General hobby airsoft
• General hobby HO scale train
• General hobby model rockets
• General hobby Pinewood Derby
• General hobby plastic models
• General hobby
